Product Overview
The PSwitch-N4UM is a smart 4-channel power switch module designed for mobile DVRs, vehicle cameras, and telematics systems. It ensures stable power management, safe ignition control, and synchronised system start-up and shutdown for dependable in-vehicle performance.
Full Product Description
The PSwitch-N4UM is an intelligent power control unit engineered for professional vehicle surveillance and telematics installations. Acting as an interface between the vehicle ignition system and devices such as mobile DVRs, IP cameras, or telematics trackers, it provides automated power switching, over-current protection, and voltage stabilisation.
Built to enhance system reliability and installation efficiency, the PSwitch-N4UM allows up to four independent outputs, each controllable for precise power distribution. When the ignition is turned on, the unit activates the connected devices automatically and powers them down safely when the vehicle is switched off, preventing data loss and protecting hardware longevity.
With rugged automotive-grade components, the PSwitch-N4UM is suited to fleets, buses, lorries, taxis, and logistics vehicles where reliability and consistent performance are essential.
Key Features
-
Four Independent Power Outputs – support multiple devices simultaneously
-
Intelligent Ignition Control – synchronised start-up and safe shutdown
-
Over-Voltage and Over-Current Protection – safeguards DVRs and sensors
-
Wide Voltage Input Range – suitable for 12 V and 24 V vehicle systems
-
Compact & Durable Housing – built for vibration and temperature endurance
-
LED Status Indicators – quick diagnostic visibility
-
Plug-and-Play Integration – simplifies installation with existing harnesses
-
Compatible with Streamax & Other MDVR Systems
-
Technical Specifications
Specification Details Model PSwitch-N4UM Input Voltage 8 – 36 V DC Output Channels 4 (independent) Maximum Load per Channel 2 A (nominal) Protection Over-current, over-voltage, reverse-polarity Control Mode Ignition signal / manual trigger Connectors Automotive-grade locking terminals Operating Temperature –20 °C to +70 °C Material Industrial ABS / aluminium housing Dimensions Approx. 90 × 60 × 25 mm Weight ≈ 120 g Applications
Fleet Management Systems – coordinate power between multiple telematics devices
Mobile DVR Setups – stable power switching for MDVR units and cameras
Public Transport – buses and coaches requiring ignition-linked operation
Commercial Vehicles – logistics, delivery, and utility fleet installations
Emergency Services – ensures reliable system operation during ignition cycles-
Net Weight: ~120 g
-
Shipping Weight: ~200 g (including packaging and cables)
-
Individually boxed in shock-resistant packaging
-
Bulk packaging available for installers or distributors
-
Global shipping supported
-
